MIYANO BNC34T CNC Lathe - Fanuc OT Control
No longer available
MIYANO BNC34T CNC Lathe - Fanuc OT Control
Livonia, MI
Description
MIYANO BNC-34T
Model BNC-34T, New 1990
EQUIPPED WITH: Fanuc OT CNC Control with CRT, RS232 Port for DNC System, Spindle Load Meter,(2) 6 Station Turrets, Programmable End Working Turret Provides 3 Axis Simultaneous Cutting Capability, CNC Iemca 12 ft Magazine load Barfeeder, Programmable Part Catcher w/ Parts Conveyor, Heavy Duty Slant Bed Construction, Chip Conveyor,Coolant System.
CATALOGUE SPECIFICATIONS:
Max Bar Capacity.......................................... 1-5/16"
Max Swing over the Cross Slide............................ 10.62"
Max Part Length........................................... 7-7/8"
Max Turning Diameter...................................... 4-3/4"
Cross Travel (X-Axis)..................................... 3-7/8"
Longitudinal Travel (Z-Axis).............................. 11-3/8"
Number of Turrets......................................... 2
Turret Positions.......................................... 6 Each
Spindle Speed Range....................................... 170-5000 RPM
Spindle Drive Motor....................................... 10 HP
Approximate Machine Dimension(w/o Barfeeder).............. 59" x 100"
Approximate Machine Height................................ 67"
Approximate Machine Weight................................ 6,200 LBS
Specifications
Manufacturer | MIYANO |
Model | BNC34T |
Year | 1990 |
Condition | Used |
