SWING OVER BED 25.59"
SWING OVER CARRIAGE 9.84"
MAX. TURNING DIAMETER X LENGTH 11.81" x 11.81"
SPINDLE DIAMETER 4.72"
SPINDLE NOSE JIS A2-8
TAPER HOLE 3.54"
THROUGH SPINDLE HOLE 3.15"
NO OF SPINDLE SPEED RANGES 2
SPINDLE SPEEDS 38-3800 RPM
X AXIS TRAVEL CROSS SLIDE 10.43" UPPER / LOWER TURRET
FEED RATE .00001 TO 39.37 IPR
RAPID FEED RATE 787 IPM
Z AXIS CARRIAGE TRAVEL (A) 22.4"(B) 44.88" (C) 22.44"
FEEDRATE .00001" TO 39.37 IPR
RAPID FEEDRATE 944.89"
RAPID FEED RATE 200 RPM
TURRET TYPE V12 + V12
NUMBER TOOLS ON EACH TURRET 12
