PL60LM CNC Lathe with Live tooling
No longer available
PL60LM CNC Lathe with Live tooling
Livonia, MI
Description
2015 Samsung PL60LM CNC Lathe with Live tooling, 125" between centers,
Equipped with: 21" Chuck, 5.5" bar capacity, Hydraulic Steadyrest, Fanuc Oi-TD control. Low hours.
Specifications:
Maximum Swing Over bed 40.55"
Maximum Turning Diameter 35.4"
Maximum Turning Length 125.9"
Distance Between Centers 126"
X - Axis Travel 18.5"
Z - Axis Travel 128.7"
C - Axis Travel .001 Degree Indexing
Rapid Traverse X, Z 472, 708 IPM
Spindle Nose A2-15''
Bar Capacity 5.47"
Spindle Speeds 1,500 RPM
Gear Ranges 3
Main Motor 60 HP
Turret Configuration 12
Rotary Tool Horsepower 15 HP
Maximum Tool Rpm 3,000 RPM
Tailstock Spindle Taper MT # 6
Tailstock Quill Diameter 7.08"
Machine Weight 49,000 LBS.
Equipped with
.001 FULL C-AXIS 2 RADIAL AND 2 AXIAL LIVE MILLING HOLDERS
CHIP CONVEYOR FANUC OiTD CNC CONTROL
Specifications
Condition | Used |
