MAZAK INTEGREX i-630V/6

Sold

MAZAK INTEGREX i-630V/6

Livonia, MI

Description

SPECIFICATION BED LENGTH - Capacity Maximum Machining Diameter 41.340 in / 1050 mm Turning Spindle Chuck Size 32 in / 800 mm Milling Spindle B-Axis Travel 150° Feed Axes Travel (X Axis) 56.10 in / 1425 mm Standard equipment FLOOD COOLANT SYSTEM WORK LIGHT ONE SET OF ADJUSTING TOOLS FOUNDATION KIT(LEVELING BLOCK) MAZAK STANDARD COLOR (F WHITE/S BLACK) THE SAFETY MEASURES ON WORLDWIDE LEVEL STANDARD TOOLING PACKAGE MAZATROL SMOOTHX CNC 19" COLOR LCD (TOUCH SCREEN) 2 PALLET CHANGER POWER TRANSFORMER FOR OTHER MARKETS LATHE SPINDLE(TABLE)MOTOR AC37KW(50HP) MILLING SPINDLE MOTOR AC37KW(50HP) MILLING SPINDLE SPEED 10000 RPM 43 TOOL CHAIN MAGAZINE C-AXIS 0.0001 DEGREE INCR. (TABLE) B-AXIS 0.0001 DEG/CNTRING (REQ. EIA/ISO) SPINDLE CHILLER UNIT PREP. FOR MAZAK MONITORING SYS.-B RMP600 MAZA-CHECK ABSOLUTE POSITIONING SYS (LINEAR AXES) SAFETY COVER FOR 2 PALLET CHANGER MANUAL PULSE GENERATOR(WIRED/DETACHABLE) MANUAL ROTATION OF 2PC LOADING STATION

Specifications

ManufacturerMAZAK
ModelINTEGREX i-630V/6
Year2017
ConditionUsed
Maximum machining length39.370 in / 1000 mm
Maximum speed10000 rpm
Magazine capacity43
Motor output (40 ed rating)50 hp / 37 kw
Travel (y axis)41.34 in / 1050 mm
Travel (z axis)41.34 in / 1050 mm
