2009 Hwacheon 2M-5AX - Built in 5 Axis table

2009 Hwacheon 2M-5AX - Built in 5 Axis table

$59,000 (USD)

Livonia, MI

Contact Us

orCall 732-367-4130


2009 Hwacheon 2M-5AX CNC 5-Axis Vertical Machining Center Specifications M2-5AX 5 axis Universal Machining Center Specification M2-5AX 20,000RPM A-Axis Stroke (Tilting)/C-Axis Stroke (Rotary) +30~-120/360 Compressed Air Supply (Pressure x Consumption) 0.5~0.7MPa x 690Nℓ/min Coolant 15.85 gal Coolant Motor (Spindle/Chip Flushing) 0.55/1.2 HP Distance Between Columns 58.27 inch Distance Between Columns to Spindle Center 4.72 inch Distance from Table Surface to Spindle Gauge Plane 2.95~22.64 inch Electric Power Supply 65.00 kVA Feed Motor (A/C) 5.5/5.5 HP Feed Motor (XY/Z) 5.5/9.5/5.5 HP Feedrate (X/Y/Z) 0.04~945 ipm Floor Space (LxW) 119.09 x 145.47 inch Height 121.65 inch Hydraulic 5.28 gal Lubrication 3.17 gal Max. Spindle Speed 20000.00 rpm Max. Tool Diameter (without Adjacent Tools) 3.15/6.69 inch Max. Tool Length 11.81 inch Max. Tool Weight 17.64 lb Method of Operation (Magazine/Swing Arm) Servo Motor/Servo Motor Method of Spindle Lubrication & Cooling Oil-Jet Lub. + Jacket Cooling Method of Tool Selection Memory Random NC Controller Fanuc 31i-B5 Rapid Speed (A/C) 8.3/33.3 rpm Rapid Speed (X/Y/Z) 1,969/1,969/1,969 ipm Spindle Bearing Inner Dia 2.76 inch Spindle Cooler (50/60Hz) – Inverter Type 6.7/7.5 HP Spindle Motor 30/25 HP Table Loading Capacity 661.39 lbs Table Surface Configuration (T Slots W x P - No. of Slots) 0.55 x 3.15 - 5 ea inch Tool Storage Capacity 30 (Opt.: 60) ea Type of Pull Stud MAS P40T-1 (45˚) Type of Spindle Taper Hole BBT40 (BIG-PLUS ISO#40, 7/24 Taper) Type of Tool Shank BT-40 (Opt.: CAT-40, HSK-A63) Weight 24251.00 lb Working Surface 19.69 inch X-Axis Stroke (Longitudinal Movement of Spindle) 29.50 inch Y-Axis Stroke (Cross Movement of Spindle) 25.29 inch Z-Axis Stroke (Vertical Movement of Spindle) 19.69 inch
