2013 MAZAK INTEGREX I-200S

Contact us for price

Livonia, MI

orCall 732-367-4130

Description

MAZAK INTEGREX I-200S MULTI-AXIS CNC TURNING & MILLING NEW 2013

Specifications
Capacity:
Max. Swing 658 mm
Max. Machining dia (Upper turret) 658 mm
Max. Machining dia (Lower turret) 420 mm
Max. Machining length 1519 mm
Max. Bar work capacity (Main spindle) 65 mm
Max. Bar work capacity (Second spindle) 65 mm
Travel:
X-Axis travel 615 mm
Y-Axis travel 250 mm
Z-Axis travel 1585 mm
X2-Axis travel (Lower turret) 230 mm
Z2-Axis travel (Lower turret) 1388 mm
B-Axis travel 30 deg - 210 deg
Main Spindle:
Chuck size 8"
Main Spindle speed 5000 RPM
Main Spindle nose/main spindle bore A2-6/76 mm
Bearing ID 120 mm
Minimum main spindle 0.0001 deg
Second Spindle:
Second spindle speed 5000 RPM
Second spindle travel (W-Axis) 1539 mm
Second spindle nose/Second spindle Bore A2-6/76 mm
Milling Spindle:
Milling spindle type Single spindle turret
w/ATC
Milling spindle speed 1200 RPM
Max. Milling spindle torque 120 Nm
Tool shank height 25 mm
Boring bar shank diameter 40 mm
Minimum milling spindle indexing increment 0.0001 deg
Automatic Tool:
Tool shank HSK-A63 (t63)
Changer system:
Tool storage capacity 72 tools
Max. Tool dia/length (from gauge line) 90 mm (when adj.
pocket empty) 125
mm/400 mm
Max. tool weight 12 kg
Tool selection method shortest path
Motors:
Spindle motor (30 min. rating, 40% Ed/cont. rating) 22 kW/15 kW
Second spindle motor (30 min. rating,40% ED/cont.) 18.5 kW/15 kW
Milling spindle motor (30 min. rating,40% ED/cont.) 22 kW/15 kW
Power Requirement:
Required power capacity (cont. rating) 71.33 kVA
Air source 0.5 MPA,150 L/min
Coolant Tank Capacity 510 L
Machine size:
Machine height 2720 mm
Floor space requirement 4910 mm x 2800 mm
Machine weight 16,600 kg

Equipped With
Standard equipment
COMPLETE COOLANT SYSTEM
FULL COVERAGE CHIP AND COOLANT GUARD WORK LIGHT
ONE SET OF MANUALS (CD) ONE SET OF MANUALS (PAPER) ACTIVE VIBRATION CONTROL INTELLIGENT THERMAL SHIELD INTELLIGENT SAFETY SHIELD MAZAK VOICE ADVISER VIRTUAL MACHINING
INTELLIGENT PERFORMANCE SPINDLE A INTELLIGENT MAINTENANCE SUPPORT ONE SET OF ADJUSTING TOOLS FOUNDATION KIT(PLATES)
MAZAK STANDARD COLOR (F WHITEIS BLACK) THE SAFETY MEASURES ON WORLDWIDE LEVEL MAZAK SULAMERICANA NAME PLATE MAZATROL MATRIX 2 CONTROL
19" COLOR LCD
8" THRU-HOLE CHUCK H3KT8 Z-323(1ST SPD.)
8" THRU-HOLE CHUCK H3KT8 Z-323(2ND SPD.) POWER TRANSFORMER FOR OTHER MARKETS 1ST SPINDLE MOTOR AC 22KW(30HP)
SECOND SPINDLE MOTOR AC18.SKW(25HP) 1ST SPINDLE SPEED 5000 RPM
SECOND SPINDLE SPEED 5000 RPM
36 HSK-TOOL MAGAZINE (REQUIRED TOOL) ROTARY-TOOL SPINDLE SPEED 12000 RPM C-AXIS 0.0001 DEGREE INCR.(1ST SPINDLE)
2ND SPINDLE POSITION 0.001DEG.W/O C-AXIS Y-AXIS CONTROL
B-AXIS 0.0001 DEGICNTRING (REQ. EIA/ISO) AUTO CHUCK JAWS OPEN/CLOSE (1&2 SPINDLE) CHUCK OPEN/CLOSE CONFIRM. (1&2 SPINDLE) CHUCK AIR BLAST (SECOND SPINDLE) ABSOLUTE POSITIONING SYS (LINEAR AXES) X,Y,Z PITCH ERROR COMPENSATION INPUT
EIA 1ST SPDL & MILL SPDL SIMUL ROTATION
COOLERS FOR BALL SCREW (X-AXIS) ROLLER GUIDES
COOLANT THROUGH MILLING HEAD
5KG THRU CLNT/FLOOD CLNT SIMUL-FLOWABLE OPERATOR DOOR INTERLOCK WITH LOCK-SWITCH PREP. FOR CHIP CONVEYOR (SIDE/HINGE)
USER MACRO (COMMON VARIABLES:600 PAIRS) MAZAK TAPPING/BORING TORNADO (EIA/ISO) EIA/ISO CODE INPUT FUNCTION (STANDARD) ADD. EIAIISO FUNCTIONS (REQ. EIA/1SO) INVERSE TIME FEED
SEQUENCE NUMBER COMPARISON STOP FUNCTION 3-0 COORDINATE CONVERSION
B)MAZACC-20 SOFTWARE(SHAPE COMPENSATION) ADD. WORKPIECE COORDINATE SYS. 300-PAIRS THREAD CUTTING FUNCTION
POLAR COORDINATES INPUT (EIA)
DIRECT ENTRY OF DRAWINGS DIMENSIONS EIA PATTERN CYCLE (GRID, ARC)
CARDBUS 1/F (2-SLOT)
LAN PORT
Additional equipment - included in the package price
8" THRU-HOLE CHUCK BB-08 (1ST SPINDLE) ONE SET OF HARD JAWS FOR B-208
TOOL EYE {AUTOMATIC)
SIGNAL TOWER (3 COLORS LIGHTS.SQUARE) CHIP-CONVEYOR SIDE DISPOSAL (CONSEP) B)CYLINDRICAL & POLAR COORDINATE (EIA)
B)MILLING-SPINDLE SYNCHRONOUS TAPPING
SCALE FEEDBACK SYSTEM FOR X,Y-AXIS SCALE FEEDBACK SYSTEM (Z-AXIS) AUTO POWER OFF{BREAKER TRIP)
15KG THRU CLNT/FLOOD CLNT SIMUL-FLOWABLE
A.P.C.(D:65 X L:120 X 2.5KG) W/EJECTOR MAXIMUM PROGRAM SIZE : 8MB
F)TOOL RADIUS COMPENSATION/ 5-AXIS EIA DYNAMIC COMPENSATION I
2ND SPDL C-AX. SYNC(FACT. INSTALL ONLY) DOUBLE FOOT SWITCH {1ST&2ND SPINDLE) PREPARATION FOR MULTI & FLASH TOOL SYS. 72 HSK-TOOL MAGAZINE {REQUIRED TOOL)
5-AXIS MACHINING PACKAGE HOBBING FUNCTION W/O TOOLING BARFEEDER INTERFAC E KIT
WORKPIECE CONVEYOR FOR A.P.C W/WORK STND
5-AXIS MACHINING PACKAGE
B)MAZACC-2D SOFTWARE{SHAPE COMP! D)MAZACC-3D HIGH-SPEED SOFTWARE F B)SHAPE COMPENSATION FOR ROTARY J
D)H IGH SMOOTHING CONTROL (REQ.MA2
F)EIA/ISO FUNCTION SIMULTANEOUS 5 A:, F)TOOL TIP POINT CONTROL /SIMULT. 5 P FINE SPLINE INTERPOLATION (EIA)
MAZAK MONITORING SYSTEM B {RMP60)

Specifications

ManufacturerMAZAK
ModelINTEGREX I-200S
Year2013
ConditionUsed
