2011 HAAS VF-6SS

Livonia, MI


2011 Haas VF6SS Vertical Machining Center

Super-Speed Vertical Machining Center; 64" x 32" x 30" (1626 x 813 x 762 mm),
40 taper,
30 hp (22.4 kW) vector drive,
12,000 rpm,
inline direct-drive, high-speed 24+1 side-mount tool changer,
900 ipm (22.9 m/min) X rapids, 1200 ipm (30.5 m/min) Y & Z rapids,
automatic chip auger,
programmable coolant nozzle, c
olorremote jog handle,
1 MB program memory, 15" color LCD monitor, USB port, memory lock keyswitch,
rigid tapping and 95-gallon (360 liter) flood coolant system.

VMC Options
COORD Coordinate Rotation & Scaling
HSM High-Speed Machining
MACRO user-definable macros
30-10474 side-Mount Tool Changer, 40-taper, 40+1 tools
RJH-C Remote Jog Handle with color LCD.
SOM spindle orientation
LK1 lifting kit
4AXBL 4th-Axis Drive and Wiring
PCOOL-O Programmable Coolant Nozzle
PFDM Early power failure detection module. Protects the work-piece and cutting tool from damage by sensing power failure and prevents the spindle from dropping.
WIPS-R wireless intuitive probing system; renishaw
TSC50T Through spindle coolant, 300 PSI (21 bar)
MACC-2 Multi-Auger Chip Conveyor System; quad side augers and belt-type chip conveyor
VQC Visual Quick Code
AAG Automatic Air Gun
HIL High-Intensity Lighting
EXPANDED-MEMORY 750 MB expanded memory
