2004 FADAL VMC 8030HT 82.5 X 30 TABLE, 80X 30Y 30Z, 10,000 RPM,

2004 FADAL VMC 8030HT 82.5 X 30 TABLE, 80X 30Y 30Z, 10,000 RPM,

Contact us for price

Illinois

Contact Us

orCall 732-367-4130

Description

FADAL VMC 8030-HT 82.5 X 30 TABLE, 80X 30Y 30Z, 10,000 RPM, CAT 40, 30 ATC, 20 HP, FADAL CNC NEW 2004 Specifications FADAL 8030HT Specifications: Travels: X-Axis: 80″ Y-Axis: 30″ Z-Axis: 30″ Rapid Traverse Rates: 400 Inch Per Minute Spindle Nose to Table (Min.- Max.): 5.5″ – 35.5″ Table: Length: 82.5″ Width: 30″ Number of Std T-Slots: 5 T-Slot Width: 5/8″ Max Weight on Table: 3750 lbs Spindle: Taper Size: CAT 40 Speed Range: 0 – 10,000 RPM Spindle Power: 20 HP Max Torque: 230ft-lb @ 500RPM Automatic Tool Changer: Capacity: 30 + 1 Max Tool Weight: 15 lbs Max Tool Dia: 6″ Max Tool Length: 15″ Tool Changing Time: 4.2 Seconds General: Air Required: 100 psi, 4 scfm Power: 480v / 1 kva / 3-Phase Overall Dimensions: 210″ x 104″ x 120″ High Weight: 20000 lbs FADAL MP CNC CONTROL 20HP High Torque Spindle Motor 10,000 RPM High Precision Spindle 30 Station Automatic tool changer Remote Jog Handle Floppy Drive Rigid Tapping Advanced Tool Management Power Failure Detection Module User Definable Macros, Spindle Orientation and Coordinate Rotational Scaling Brushless type servo drive motors on all axis Programmable coolant Telescopic way covers Chip auger Flood Coolant system

Specifications

ManufacturerFADAL
ModelVMC 8030HT
Year2004
ConditionUsed
