2016 Tsugami B038TE

2016 Tsugami B038TE

Contact us for price

Livonia, MI

Contact Us

orCall 732-367-4130

Description

38MM TSUGAMI B038TE 9-AXIS PRECISION CNC TURNING CENTER LATHE 2016 Specifications Max. Bar Stock 38 mm Number of Axes 9 Sliding Headstock/Guide Bushing Yes Convertible Run w/o Guide Bushing (Chucker) No Tool Positions (std/max) 45 Max. Live Tool Positions (std/max) (Turret) 8 Rotary Tools Control Fanuc 31i-B Main Spindle Speed 200-5,000 RPM Sub Spindle Speed 200-7,000 RPM Live Tool Speed 200-8,000 RPM Main Spindle Motor 7.5/11 kW Weight (approx) 6,200 kg Footprint (wxdxh) 3247x1875x1840 mm Machining Range Main Spindle Max. Chucking Barstock Dia. 8-38 mm Max. Machining length 250 mm Max. Drilling Dia 16 mm Max. Tapping Dia M14 Back Spindle Turret Max. Spindle Chucking Dia 38 mm Max. Spindle Drilling Dia 16 mm Max. Spindle Tapping size M12 Front Tool Post Max. Cross Drilling Dia 10 mm Max. Cross Tapping size Dia M6 Turret Max. Rotary Tool Drilling Dia 16 mm Max. Rotary Tool Tapping size M10 Back Tool Post Max. Rotary Tool Drilling Dia 8 mm Max. Rotary Tool Tapping Size M6 Max. Fixed Tool Drilling Dia 10 mm Max. Fixed Tool Tapping Size M10 Machine Capacity Main Spindle speed 200-5000 RPM Back Spindle Speed 200-7000 RPM Cross Drill Speed on Front Post 200-5000 RPM Total Tool Number (standard spec) 200-8000 RPM Main & Back Spindle INdexing C-Axis Motor Main Spindle 7.5/11 kW Back Spindle 3.7/5.5 kW Live Tool on Front Tool Post 1 kW Live Tool on Turret 1.4 kW Live Tool on Back tool post 1 kW Coolant pump 0.4 kW Lubricating Pump 3 W Compressed air requirement 0.5 MPa or above Air discharge rate 100 NL/min Power source requirements 45 kVA Total Tool Storage Capacity Turret 8 stations (4x8=32 sta) Front tool post (standard) Turning 7 Front tool post Turning 3 Cross drill 3 (optional) Tool size Turret 20mmx20mmx125mm Front tool post 16mmx16mmx125mm Rapid Traverse rate X1,X2,X3 24m/min Y1,Y2,Y3 24m/min Z1,Z2,Z3 24m/min Equipped With Fanuc 31iB CNC Controls Special Packaged Options Signal tower 3-stage, Work Conveyor, Chip Conveyor (flat type), Work front discharge with M-code oil blow Turret Coolant piping with M-code oil blow C-Axis Control for Main & Back Spindle Tool Box, N.4 Drill Holder (diam. 32, turret/ref .3262-H01A) (2) 2-Drill Holder (diam 25x2), (5) Turning Holder (20 sq) Front Holder (20 sq), (2) Cross Drill Head 3-Spindle Cross Drill + 3 Pos. OD Tools (6) Drill Holder for Back Tool post (2) 2-Turning Holder, (2) Power Drill Head Rigid Tapping Function (3-Cross, Turret tool, back tool) Helical & Cylindrical interpolation Polar Coordinate Interpolation Handle retrace function, European display Main Spindle adaptor (Schaublin 76-00740 F37 Max Diam 32) Sub Spindle adaptor (Scahublin 76-00740 F37 Max diam 32) Guide Bush adaptor (Neukonm 28.001 max diam 32) M-Code oil blow (Turret, Ejector, main Spindle, Back Spindle, Back Tool post) Coolant block for back tool post (3) Back adaptor (diam. 25), Bar feeder interface, R232C Interface High Pressure Coolant 1,5W (2MPa) Main Spindle adaptor (for Dunner F47/37 AC or Tsugami 2601-1234 max diam 38) Back Spindle adaptor (for Dunner F48/38 AC or Tsugami 2601-5230 max diam 38) Guide Bush adaptor (for Dunner B240 or Tsugami 2621-1234 max diam 38) Record-S Magazine Type Bar Feeder

Specifications

ManufacturerTsugami
ModelB038TE
Year2016
ConditionUsed
